Electrosurgical Cautery Machine
Surgical Equipment (Surgical cautery) were first introduced during the early twentieth century to facilitate homeostasis and/or the cutting of tissue during surgical procedure.
This is achieved by passing normal electrical current via the surgical diathermy and converting it into a high frequency alternating current (HFAC). The HFAC produces heat within body tissues to coagulate bleeding vessels and cut through tissue.
There are two different types of diathermy machine: monopolar and bipolar.
Mono Polar/Bipolar Surgical Diathermy
AYU 250 ANL is a high frequency Electro Surgical Unit Micro controller based innovative design, together with high reliability makes AYU 250 ANL Electro Surgical Diathermy unit the most favorable choice of doctors. The technical ability of the unit is combined with patient's safety that are of prime importance both for patient and the user. The AYU 250 ANL Electro Surgical Diathermy is designed with SMPS power supply which provides particular safety and reliability. AYU 250 ANL is user friendly Electro Surgical unit.
SAFETY IN USE
The Technical conceptions of the AYU 250 ANL meet the requirements of highly refined Electro Surgical techniques all national and international safety standards are confirmed. The micro function and knob allows for an instant variation in the output power for more delicate application such as neurological or micro surgery.
-
Ortho Peallic
-
Dermatology
-
Otolaryngology
-
Ophthalmology
-
Ginaecology
-
Aesthetics
-
Vascular Disease
| SPECIFICATIONS | ||||
| MODE | RATED LOAD (OHMS) | MAXIMUM POWER(WATTS) | ||
| Monopolar Cut |
Pure Blend |
300 300 |
250 180 |
|
| Monopolar Coag. |
Force Soft |
300 300 |
180 150 |
|
| Bipolar Cut |
Pure Blend |
100 100 |
100 70 |
|
| Bipolar Coag |
Force Soft |
100 100 |
70 50 |
|
Unit Size - L*W*H - 335x330x125 mm
Box Size
- L*W*H - 430x405x280 mm
Net Weight - 5kg.200gm Gross Weight - 10kg . 500gm
Mono Polar/Bipolar Digital Surgical Diathermy
AYU 250 ECO DIGITAL ELELTRO SURGICAL UNIT is a high frequency Electro Surgical Unit Micro controller based innovative design, together with high reliability makes AYU 250 ECO Electro Surgical Diathermy unit the most favorable choice of doctors. The technical ability of the unit is combined with patient's safety that are of prime importance both for patient and the user. The AYU 250 ECO Electro Surgical Diathermy is designed with SMPS power supply which provides particular safety and reliability. AYU 250 ECO is user friendly Electro Surgical unit.
SAFETY IN USE
The Technical conceptions of the AYU 250 ECO meet the requirements of highly refined Electro Surgical techniques all national and international safety standards are confirmed. The micro function and knob allows for an instant variation in the output power.
-
Ortho Peallic
-
Dermatology
-
Otolaryngology
-
Ophthalmology
-
Ginaecology
-
Aesthetics
-
Vascular Disease
| SPECIFICATIONS | ||||
| MODE | RATED LOAD (OHMS) | MAXIMUM POWER(WATTS) | ||
| Monopolar Cut |
Pure Blend |
300 300 |
250 180 |
|
| Monopolar Coag. |
Desiccate Fulgurate |
300 300 |
150 180 |
|
| Bipolar Cut |
Pure Blend |
100 100 |
100 70 |
|
| Bipolar Coag |
Desiccate Fulgurate |
100 100 |
50 70 |
|
Unit Size - L*W*H - 355x330x125 mm
Box Size
- L*W*H - 430x405x280 mm
Net Weight - 5kg.500gm Gross Weight - 10kg . 500gm
Mono Polar/Bipolar Surgical Diathermy
AYU 42A is a high frequency Electro Surgical Unit Micro controller based innovative design, together with high reliability makes AYU 42A Electro Surgical Diathermy unit the most favorable choice of doctors. The technical ability of the unit is combined with patient's safety that are of prime importance both for patient and the user. The AYU 42A Electro Surgical Diathermy is designed with SMPS power supply which provides particular safety and reliability. AYU 42A is user friendly Electro Surgical unit.
SAFETY IN USE
The Technical conceptions of the Ayu-400W-ANL meet the requirements of highly refined, Electro Surgical techniques all national and international safety standards are conformed to or exceeded. It is not possible for the unit to deliver a higher output than has been set on the control. The micro function allows for an instant reduction in the output for more delicate application such as neurological or micro surgery.
-
Ortho Peallic
-
Dermatology
-
Otolaryngology
-
Ophthalmology
-
Ginaecology
-
Aesthetics
-
Vascular Disease
-
TUR
| SPECIFICATIONS | |||||
| MODE | RATED LOAD (OHMS) | MAXIMUM POWER(WATTS) | |||
| Monopolar Cut |
Pure Blend |
300 300 |
400 300 |
||
| Monopolar Coag. |
Dessiccate Fulgurate |
300 300 |
150 250 |
||
| Bipolar Cut |
Pure Blend |
100 100 |
100 70 |
||
| Bipolar Coag |
Dessiccate Fulgurate |
100 100 |
50 70 |
||
Physical Characteristics - L*W*H - 430x405x280 mm
Net Weight - 5kg.500gm Gross Weight - 10kg . 800gm
High Frequency Electro Surgical Unit with Separate Bipolar Foot Switch
AYU 42AB is a high frequency Electro Surgical Unit Micro controller based innovative design, together with high reliability makes AYU 42AB Electro Surgical Diathermy unit the most favorable choice of doctors. The technical ability of the unit is combined with patient's safety that are of prime importance both for patient and the user. The AYU 42AB Electro Surgical Diathermy is designed with SMPS power supply which provides particular safety and reliability. AYU 42AB is user friendly Electro Surgical unit.
SAFETY IN USE
The Technical conceptions of the AYU 42AB meet the requirements of highly refined Electro Surgical techniques all national and international safety standards are confirmed. The micro function and knob allows for an instant variation in the output power for more delicate application such as neurological or micro surgery.
Features :
Lightweight
Easy installation
Simple to operate
Cost effective
Prevent accidents
Higher output
Microprocessor control
Application Areas
Gynecology
Dermatology
Ophthalmology
Otolaryngology
Vascular disease
Aesthetic
| SPECIFICATIONS | ||||
| MODE | RATED LOAD (OHMS) | MAXIMUM POWER(WATTS) | ||
| Monopolar Cut |
Pure Blend |
300 300 |
400 300 |
|
| Monopolar Coag. |
Desiccate Fulgurate |
300 300 |
150 250 |
|
| Bipolar |
Cut Coag |
100 100 |
100 70 |
|
Unit Size - L*W*H - 355x330x125 mm
Box Size
- L*W*H - 430x405x280 mm
Net Weight - 5kg.700gm Gross Weight - 11kg . 200gm
When safety is the prime concern while performing surgery diathermy, then most of the medical experts recommend 400 Watt AYU 43AB ANL. The design of this device allows safety to not only patient, but also to the user who is handling it. Thus, relying on its reliability and durability, it is installed in many operation theaters.
Features :
Cost effective
Prevent accidents
Microprocessor control
Easy installation
Lightweight
Simple to operate
Durable structure
Higher output
Application Areas
Otolaryngology
Gynecology
Ophthalmology
Vascular disease
Aesthetic
Dermatology
| SPECIFICATIONS | ||||
| MODE | RATED LOAD (OHMS) | MAXIMUM POWER(WATTS) | ||
| Monopolar Cut |
Pure Blend-1 Blend-2 |
300 300 300 |
400 300 200 |
|
| Monopolar Coag. |
Desiccate Fulgurate Spray |
300 300 300 |
150 250 120 |
|
| Bipolar Cut |
Macro Micro |
100 100 |
100 70 |
|
| Bipolar Coag. |
Macro Micro |
100 100 |
70 5 0 |
|
Unit Size - L*W*H - 355x330x125 mm
Box Size
- L*W*H - 430x405x280 mm
Net Weight - 5kg.700gm Gross Weight - 11kg . 200gm
Digital High Frequency Electro Surgical Unit with Separate Bipolar Foot Switch
AYU 400 MICRO is a high frequency Electro Surgical Unit Micro controller based innovative design, together with high reliability makes AYU 400 MICRO Electro Surgical Diathermy unit the most favorable choice of doctors. The technical ability of the unit is combined with patient's safety that are of prime importance both for patient and the user. The AYU 400 MICRO Electro Surgical Diathermy is designed with SMPS power supply which provides particular safety and reliability. AYU 400 MICRO is user friendly Electro Surgical unit.
SAFETY IN USE
The Technical conceptions of the AYU 400 MICRO meet the requirements of highly refined Electro Surgical techniques all national and international safety standards are confirmed. The micro function and knob allows for an instant variation in the output power for more delicate application such as neurological or micro surgery.
Features :
Cost effective
Prevent accidents
Microprocessor control
Easy installation
Lightweight
Simple to operate
Durable structure
Higher output
Application Areas
Otolaryngology
Gynecology
Ophthalmology
Vascular disease
Aesthetic
Dermatology
| SPECIFICATIONS | ||||
| MODE | RATED LOAD (OHMS) | MAXIMUM POWER(WATTS) | ||
| Monopolar Cut |
Pure Blend |
300 300 |
400 300 |
|
| Monopolar Coag. |
Desiccate Fulgurate |
300 300 |
150 250 |
|
| Bipolar |
Cut Coag |
100 100 |
100 70 |
|
Unit Size - L*W*H - 355x330x125 mm
Box Size
- L*W*H - 430x405x280 mm
Net Weight - 5kg.700gm Gross Weight - 11kg . 200gm
Digital High Frequency Electro Surgical Unit with Separate Bipolar Foot Switch
AYU 400 MAXI is a high frequency Electro Surgical Unit Micro controller based innovative design, together with high reliability makes AYU 400 MAXI Electro Surgical Diathermy unit the most favorable choice of doctors. The technical ability of the unit is combined with patient's safety that are of prime importance both for patient and the user. The AYU 400 MAXI Electro Surgical Diathermy is designed with SMPS power supply which provides particular safety and reliability. AYU 400 MAXI is user friendly Electro Surgical unit.
SAFETY IN USE
The Technical conceptions of the AYU 400 MAXI meet the requirements of highly refined Electro Surgical techniques all national and international safety standards are confirmed. The micro function and knob allows for an instant variation in the output power for more delicate application such as neurological or micro surgery.
Features :
Cost effective
Prevent accidents
Microprocessor control
Easy installation
Lightweight
Simple to operate
Durable structure
Higher output
Application Areas
Otolaryngology
Gynecology
Ophthalmology
Vascular disease
Aesthetic
Dermatology
| SPECIFICATIONS | ||||
| MODE | RATED LOAD (OHMS) | MAXIMUM POWER(WATTS) | ||
| Monopolar Cut |
Pure Blend Endo Cut |
300 300 300 |
400 300 200 |
|
| Monopolar Coag. |
Desiccate Fulgurate Spray |
300 300 300 |
150 250 120 |
|
| Bipolar |
Cut Coag |
100 100 |
120 100 |
|
Unit Size - L*W*H - 355x330x125 mm
Box Size
- L*W*H - 430x405x280 mm
Net Weight - 5kg.700gm Gross Weight - 11kg . 200gm
High Frequency Electro Surgical Unit with Separate Bipolar Foot Switch
Microprocessor control, innovative design, together with high reliability makes 400W ALLIGATOR high frequency Surgical Units the most favorable choice for doctors.
In the used surgical diathermy, the technical ability of the unit combined with plain safety are of prime importance —both for the patient and the user, There must be no possibility of accidental , undesirable results in the use of life care systems Electro Surgical Units been developed .
The Ayu 400W ALLIGATOR is newly developed electro surgical units of particular safety and reliability. The Ayu 400W ALLIGATOR as the most refined unit of its kind in the world.
Safety in use
The Technical conceptions of the Ayu 400W ALLIGATOR meet the requirements of highly refined, Electra Surgical techniques all national and international safety standards are conformed to or exceeded. It is not possible for the unit to deliver a higher output than has been set on the control. The micro function allows for an instant reduction in the output for more delicate application such as neurological or micro surgery.
AYU-400W ALLIGATOR :
Light weight
Elegant Design
Simple Operation
The Reliable Economical
Digital Display
100 Programs
| SPECIFICATIONS | ||||
| MODE | RATED LOAD (OHMS) | MAXIMUM POWER(WATTS) | ||
| Monopolar Cut |
Pure Blend-1 Blend-2 Endo Cut |
300 300 300 300 |
400 400 250 200 |
|
| Monopolar Coag. |
Desiccate Fulgurate Force Spray |
300 300 300 300 |
150 250 200 120 |
|
| Bipolar |
Cut Coag Macro Micro |
100 100 100 100 |
120 100 70 50 |
|
Unit Size - L*W*H - 355x330x125 mm
Box Size
- L*W*H - 430x405x280 mm
Net Weight - 5kg.700gm Gross Weight - 11kg . 200gm
